Application:
1. Widely used in foam working, woodworking and acrylics working.
2. Strong machine body, reliable and durable, with long working life.
3. Easy and safe operation and low maintenance cost.
4. Breakpoint specifific memory keeps the carving status when power offff. 5. Top-quality components, to make the machine high-precision and high-effiffifficiency. Keep the machine in the best condition even after working for many years.
6. The spindle is 1.5 KW（4.5 KW） air-cooling.
7. Auto lubrication system and separated control system, easy to operate. 8. High-performance driven motor ensures the machine’s high speed and accuracy.
Technical Data
| Model No. | KD-PD1325 | KD-PD2030 |
| Working Stroke(L*W*H) | 2500*1300*950 mm | 3000*2000*1000 mm |
| Overall Size | 3700*2200*2200 mm | 4200*2900*2200 mm |
| Working Table | 3700*1680 mm | 4200*2380 mm |
| Rotary Spindle | Ø 600 mm | Ø 600 mm |
| Drive Motor | Mixed Servo | Mixed Servo |
| Production Precision | 0.5 mm | 0.5 mm |
| Max. Running Speed | 10 m/min | 10 m/min |
| Spindle Speed | 0~6000 r/min | 0~6000 r/min |
| lubrication system | Automatically | Automatically |
| N.W. | 1600 Kgs | 2200 Kgs |
Basic Kit Include:
1 * KD-PD CNC Router
1 * Special Wrench
1 * Rotary Spindle
1 * Foam Fixing Device
Drawing Software: 3Dmax、SOLIDWORK、Rhino、JDpaint、UG
